Motorized Bioclimatic Louvered Pergola

SOLVE Outdoor Space Solutions

Refine your tasteful life and create wonderful outdoor scenery

Movable Louver Pergola Product Introduction

This movable louver pergola is an all-aluminum architectural structure with flexible multi-form transformation. The top blades can be fully folded and stacked to one side. When all blades are fully retracted, up to 75% of light can pass through, bringing you a full panoramic view of the sky. When the blades are closed completely, it can block direct sunlight and resist rainwater. Made of high-performance aluminum material, it can withstand harsh outdoor weather conditions, features solid construction and long service life up to 20 years.

Core Product Advantages

• Full aluminum alloy structure
• Built-in LED ambient light strips
• Remote electric control system
• Strong wind resistance performance
• Integrated rainproof & drainage design
• Effective heat insulation and sun shading

Size & Frame Combination Options

We provide multiple customizable frame combinations to match different space sizes, all supporting electric motor drive:

1. Four-post Group A: Maximum span size 4m by 7m
2. Six-post Group B: Maximum span size 8m by 7m
3. Six-post Group C: Maximum span size 14m by 4m

Ambient LED Lighting System

LED light strips are embedded inside the surrounding gutter, forming a full-circle soft lighting layout to create a comfortable atmospheric outdoor environment.

Fully Retracted Working State

All top louver blades can slide and stack neatly to one side, eliminating visual barriers and greatly expanding the open outdoor view space.

Main Aluminum Extrusion Profiles & Specifications

Component A is the louver blade, with dimension 228mm40mm, wall thickness 1.8mm.
Component B refers to the side beam, sized 250mm50mm with 2.3mm wall thickness.
Two types of gutters are available for Component C: large gutter 157mm58mm (1.5mm thickness) and standard gutter 142mm58mm (1.5mm thickness).
Component D is the support post, specification 200mm200mm, wall thickness 3.0mm.
Component E stands for the sliding track, dimension 142mm80mm, wall thickness 2.0mm.

Optional Matching Accessories

We support various matching combinations to satisfy personalized decoration demands:

• Louver pergola matched with ceiling fans
• Louver pergola matched with windproof roller screens
• Louver pergola matched with soft curtains

Rainwater Drainage Principle

Rainwater flows along the built-in grooves of each louver blade into the surrounding integrated gutter. Drain outlets are reserved at the bottom of every support post to discharge all rainwater outside the structure.

Premium Material & Superior Performance

All parts adopt carefully selected aluminum alloy raw materials. The surface is finished with eco-friendly high-quality spraying coating. The gutter is pre-installed with environmentally friendly LED light strips for decorative lighting.

Application Scenarios

This louver pergola fits a wide range of outdoor occasions, including lawn yards, seaside terraces, bars and night markets, homestay gardens, rooftop patios and more.

Frame & Louver Color Matching Schemes

Multiple color collocations are available for selection:
Black frame with white louvers
Grey frame with white louvers
White frame with wood grain louvers
Full wood grain finish
All white finish
All black finish

Two matching styles for reference: mixed color matching and solid classic color matching.

Expand your ideal outdoor world, more customized options are available for you to choose.
